Mic Input:
Electronically balanced, input impedance greater than 10Kohm, to suit 150-600 ohm microphones.
First stage solid state, second stage triode valve.
48V phantom power available, via switch.
Gain range 10 to 60dB.
Noise (EIN): -127Bu at maximum gain with a 150 ohm termination, measured 22Hz-22KHz unweighted. Maximum input level 10dBu.
3 pin female XLR connector.
Instrument Input:
(instrument).
Outputs:
Unbalanced, input impedance 100Kohm (guitar), 10Kohm
Nominal sensitivity for 0dBu output -35dBu (guitar), -15dBu (instrument).
Two stage, triode valve amplifier.
Unbalanced jack socket input.
Direct wired through connection, also on unbalanced jack.
Electronically balanced, unbalanced compatible.
Output impedance 47 ohms.
Maximum level 26dBu into 10Kohms, 22dBu into 600 ohms. 3 pin male XLR connector.
Switchable output for line level or mic (30dB pad).
SPECIFICATIONS
Frequency Response:
20Hz to 40KHz, 0, -1dB, mic input at 20dB gain.
Noise: Mic EIN -127dBu (Maximum gain 22Hz-22KHz, input terminated in 150 ohms).
Distortion:
THD N: 0.05% at 1KHz, mic input at 20dB gain, 0dBu output.
