REX 30 kVA ISOLATION TRANSFORMER – 600V TO 220Y/127V – COPPER – TESTED – BC30JS2 – MUST GO BY FRIDAY
Rex Manufacturing (Rexdale, ON) 30 kVA 3-phase isolation transformer, catalogue # BC30JS2. CSA listed.
SPECS: 30 kVA, 3-phase, 60 Hz, Type ANN, Enclosure Type-1. Primary: 600V Delta (H1-H2-H3). Secondary: 220Y/127V (X0-X1-X2-X3). Taps: 105% / 102.5% / 100% / 97.5% / 95%. Impedance 6.5%, insulation class 220 C, temperature rise 150 C. Copper windings (per Rex catalogue), Cu-Al rated terminals, 290 lbs. Serial: A 74631.
CONDITION: Tested — confirmed working 2026-10-26. Dusty from warehouse storage, enclosure intact. Unit is wall-mounted high on the warehouse wall — see photos.
REMOVAL (READ THIS): The seller will have the unit disconnected. The BUYER is responsible for bringing it down — bring your own rigging, lift, and crew. Priced with that in mind.
WHY THIS UNIT: 220Y/127V output feeds older Canadian industrial equipment and imported 220V machinery — a standard, usable voltage, not a one-off. The current copper equivalent runs about $5,319 CAD new; used 30 kVA units in Toronto have sold at $1,200–$1,350. Asking $1,250 OBO — must go by Friday.
Message to arrange pickup. Call Mohab — 289-788-8085. They're not just Good Finds, they're GREAT FINDS!
